Testing AMD E2-3300M CPU online in 1 benchmarks. Detailed study of all main characteristics of the processor model AMD E2-3300M: runs on 2 cores with a base clock frequency 1.80 GHz, manufacturing microprocessor architecture Llano. The second L2 and third level memory cache size is L3 - -- / L3 1.00 MB.
AMD E2-3300M in 1 Benchmarks. 32 nm, 1.80 GHz
Basic specifications AMD E2-3300M
Detailed review of the processor AMD E2-3300M in terms of specifications, benchmark results (when performing complex calculations, rendering, big data processing and other graphical scenarios). Carefully review all specifications of the AMD E2-3300M processor before you buy it on Amazon, Ebay or Aliexpress. We recommend that you consider comparing several similar options (based on ratings or from a special ratings page), this way you can upgrade your computer or laptop as efficiently as possible for several years. After familiarizing yourself with the main technical characteristics of the model, check the results of benchmark tests.
Technical specs
Technical information about the characteristics of the processor AMD E2-3300M reveals important data that will help to make the right choice in favor of upgrading your computer or laptop to a more modern model.
Before we explore the detailed specifications AMD E2-3300M we want to inform you that we will help with the answers to the following questions:
1) How many cores and threads does the processor AMD E2-3300M have?
2) Is the processor AMD E2-3300M productive enough for games or work programs?
3) Can I mine on a AMD E2-3300M processor?
| Cores: | 2x | |||
| CPU Cores / Threads: | 2 / 2 | |||
| Core architecture: | normal | |||
| Hyperthreading: | No | |||
| Overclocking: | Yes | |||
| Frequency: | 1.80 GHz | |||
| Turbo Frequency (1 Core): | 2.20 GHz | |||
| Turbo Frequency (2 Cores): | 2.20 GHz | |||
CPU generation and family
Processor generation AMD E2-3300M, as well as the family have an important role in the analysis of data. As a rule, you should pay attention not to the generation and family of the processor model when you upgrade your computer system, because the new families have a difference in the motherboard socket, which will entail additional costs for upgrading. Otherwise, each subsequent generation is improved by adding new and efficient processors to the family.
| Name: | AMD E2-3300M | |||
| Family: | AMD E | |||
| CPU group: | AMD E2-3000 | |||
| Generation: | 3 | |||
| Segment: | Mobile | |||
| Predecessor: | -- | |||
| Successor: | -- | |||
iGPU
Not every processor model supports an integrated graphics core, but this is a nice bonus for those who do not need a separate graphics card. See if the AMD E2-3300M processor has an integrated graphics core and what features the manufacturer has implemented in this model.
| GPU name: | AMD Radeon HD 6480G | |||
| GPU frequency: | 0.44 GHz | |||
| GPU (Turbo): | No turbo | |||
| Execution units: | 3 | |||
| Shader: | 240 | |||
| Max. GPU Memory: | 1 GB | |||
| Max. displays: | 2 | |||
| Generation: | 3 | |||
| Direct X: | 11 | |||
| Technology: | 32 nm | |||
| Release date: | Q2/2011 | |||
Hardware codec support
Find out which hardware codecs are supported by the processor AMD E2-3300M. Most often manufacturers embed proprietary add-ons, which are disclosed in the operating system by their functionality, so this unit is not considered in the overall performance rating of the model.
| h265 8bit: | No | |||
| h265 10bit: | No | |||
| h265 / HEVC (8 bit): | No | |||
| h265 / HEVC (10 bit): | No | |||
| h264: | Decode | |||
| VP8: | No | |||
| VP9: | No | |||
| AV1: | No | |||
| AVC: | Decode | |||
| VC-1: | Decode | |||
| JPEG: | Decode / Encode | |||
Memory Specifications
The type of memory supported, the number of supported RAM channels, its standard and bandwidth all affect the overall performance of the AMD E2-3300M CPU. The type and maximum amount of memory the CPU supports will determine the model's performance in games, work applications, or mining. Pay attention to all parameters, especially useful when comparing two CPUs.
| Memory type: | DDR3-1333 | |||
| Memory channels: | 1 | |||
| Bandwidth: | -- | |||
| ECC: | No | |||
| AES-NI: | Yes | |||
Thermal Management (TDP)
The TDP values for the processor AMD E2-3300M are shown in the table below. These parameters are very important and especially useful when choosing a new processor model to replace an old one. The TDP figure shows how much power you will need and what kind of cooling system you will need. Also, depending on the type of power supply, you may need a good motherboard with good quality power phases for your CPU and graphics card.
| TDP: | 35 W | |||
| TDP (PL1): | 35 W | |||
| TDP (PL2): | -- | |||
| TDP up: | -- | |||
| TDP down: | -- | |||
| Tjunction max.: | -- | |||
Additional specifications
Detailed processor specifications AMD E2-3300M. Here you will find out the L2 and L3 memory size (cacheable and affecting data processing). The manufacturing process is also very important, it is measured in nanometers and the smaller the better. As a rule, only the most modern models are produced by the manufacturing method of lithography. Also here is information on the socket of the motherboard and the date of manufacture of the model, the fresher the processor, the longer it will last until the next upgrade.
| Instruction set (ISA): | x86-64 (64 bit) | |||
| ISA extensions: | SSE3, SSE4a | |||
| L2-Cache: | -- | |||
| L3-Cache: | 1.00 MB | |||
| Architecture: | Llano | |||
| Technology: | 32 nm | |||
| Virtualization: | AMD-V | |||
| Socket: | FS1 | |||
| Release date: | Q3/2011 | |||
| Part Number: | -- | |||
Use Conditions
We are updating information about the use and destination of the AMD E2-3300M processor, so if you have exact information about where the model is used, please let us know via the feedback form.
| Used in: | Unknown | |||
