Testing Intel Core i3-8145UE CPU online in 1 benchmarks. Detailed study of all main characteristics of the processor model Intel Core i3-8145UE: runs on 2 cores with a base clock frequency 2.20 GHz, manufacturing microprocessor architecture Whiskey Lake. The second L2 and third level memory cache size is L3 - / L3 4.00 MB.
Intel Core i3-8145UE in 1 Benchmarks. 14 nm, 2.20 GHz
Basic specifications Intel Core i3-8145UE
Detailed review of the processor Intel Core i3-8145UE in terms of specifications, benchmark results (when performing complex calculations, rendering, big data processing and other graphical scenarios). Carefully review all specifications of the Intel Core i3-8145UE processor before you buy it on Amazon, Ebay or Aliexpress. We recommend that you consider comparing several similar options (based on ratings or from a special ratings page), this way you can upgrade your computer or laptop as efficiently as possible for several years. After familiarizing yourself with the main technical characteristics of the model, check the results of benchmark tests.
Technical specs
Technical information about the characteristics of the processor Intel Core i3-8145UE reveals important data that will help to make the right choice in favor of upgrading your computer or laptop to a more modern model.
Before we explore the detailed specifications Intel Core i3-8145UE we want to inform you that we will help with the answers to the following questions:
1) How many cores and threads does the processor Intel Core i3-8145UE have?
2) Is the processor Intel Core i3-8145UE productive enough for games or work programs?
3) Can I mine on a Intel Core i3-8145UE processor?
| CPU Cores / Threads: | 2 / 4 | |||
| Hyperthreading: | Yes | |||
| Overclocking: | No | |||
| Frequency: | 2.20 GHz | |||
| Turbo Frequency (1 Core): | 3.90 GHz | |||
| Turbo Frequency (2 Cores): | No turbo | |||
CPU generation and family
Processor generation Intel Core i3-8145UE, as well as the family have an important role in the analysis of data. As a rule, you should pay attention not to the generation and family of the processor model when you upgrade your computer system, because the new families have a difference in the motherboard socket, which will entail additional costs for upgrading. Otherwise, each subsequent generation is improved by adding new and efficient processors to the family.
| Market price: | ca. 281 $ | |||
| Generation: | 9.5 | |||
iGPU
Not every processor model supports an integrated graphics core, but this is a nice bonus for those who do not need a separate graphics card. See if the Intel Core i3-8145UE processor has an integrated graphics core and what features the manufacturer has implemented in this model.
| GPU name: | Intel UHD Graphics 620 | |||
| GPU frequency: | 0.30 GHz | |||
| GPU (Turbo): | 1.00 GHz | |||
| Execution units: | 24 | |||
| Shader: | 192 | |||
| Max. displays: | 3 | |||
| Generation: | 9.5 | |||
| Direct X: | 12 | |||
| Technology: | 14 nm | |||
| Release date: | Q3/2016 | |||
Hardware codec support
Find out which hardware codecs are supported by the processor Intel Core i3-8145UE. Most often manufacturers embed proprietary add-ons, which are disclosed in the operating system by their functionality, so this unit is not considered in the overall performance rating of the model.
| h265 8bit: | Decode / Encode | |||
| h265 10bit: | Decode / Encode | |||
| h264: | Decode / Encode | |||
| VP8: | Decode / Encode | |||
| VP9: | Decode / Encode | |||
| AVC: | Decode / Encode | |||
| VC-1: | Decode | |||
| JPEG: | Decode / Encode | |||
Memory Specifications
The type of memory supported, the number of supported RAM channels, its standard and bandwidth all affect the overall performance of the Intel Core i3-8145UE CPU. The type and maximum amount of memory the CPU supports will determine the model's performance in games, work applications, or mining. Pay attention to all parameters, especially useful when comparing two CPUs.
| Memory type: | DDR4-2400 SO-DIMM LPDDR3-2133 | |||
| Max. Memory: | 64 GB | |||
| Memory channels: | 2 | |||
| ECC: | Yes | |||
| AES-NI: | Yes | |||
Thermal Management (TDP)
The TDP values for the processor Intel Core i3-8145UE are shown in the table below. These parameters are very important and especially useful when choosing a new processor model to replace an old one. The TDP figure shows how much power you will need and what kind of cooling system you will need. Also, depending on the type of power supply, you may need a good motherboard with good quality power phases for your CPU and graphics card.
| TDP: | 15 W | |||
| TDP up: | 25 W | |||
| TDP down: | 12.5 W | |||
| Tjunction max.: | 100 °C | |||
Additional specifications
Detailed processor specifications Intel Core i3-8145UE. Here you will find out the L2 and L3 memory size (cacheable and affecting data processing). The manufacturing process is also very important, it is measured in nanometers and the smaller the better. As a rule, only the most modern models are produced by the manufacturing method of lithography. Also here is information on the socket of the motherboard and the date of manufacture of the model, the fresher the processor, the longer it will last until the next upgrade.
| L3-Cache: | 4.00 MB | |||
| Architecture: | Whiskey Lake | |||
| Technology: | 14 nm | |||
| Virtualization: | VT-x, VT-x EPT, Vt-d | |||
| Socket: | BGA 1528 | |||
| Release date: | Q2/2019 | |||
Use Conditions
We are updating information about the use and destination of the Intel Core i3-8145UE processor, so if you have exact information about where the model is used, please let us know via the feedback form.
| Used in: | Unknown | |||
iGPU - FP32 Performance Intel Core i3-8145UE
The best processor for programming with high performance will be easy to find. The rating of computer processors is at your disposal. compiled taking into account price and performance. It is necessary to pay attention to the following: - Which processor is best for gaming and productivity? - Which CPU is fastest for gaming? - What is the best CPU for gaming and editing? - What is the most powerful gaming CPU? The best single-core or multi-core processor with good performance will always be at your disposal. Use our top to buy a good new processor.
