Testing Intel Xeon W-2235 CPU online in 1 benchmarks. Detailed study of all main characteristics of the processor model Intel Xeon W-2235: runs on 6 cores with a base clock frequency 3.80 GHz, manufacturing microprocessor architecture Cascade Lake SP / Glacier Falls W. The second L2 and third level memory cache size is L3 - 6.00 MB / L3 8.25 MB.
Intel Xeon W-2235 in 1 Benchmarks. 14 nm, 3.80 GHz
Basic specifications Intel Xeon W-2235
Detailed review of the processor Intel Xeon W-2235 in terms of specifications, benchmark results (when performing complex calculations, rendering, big data processing and other graphical scenarios). Carefully review all specifications of the Intel Xeon W-2235 processor before you buy it on Amazon, Ebay or Aliexpress. We recommend that you consider comparing several similar options (based on ratings or from a special ratings page), this way you can upgrade your computer or laptop as efficiently as possible for several years. After familiarizing yourself with the main technical characteristics of the model, check the results of benchmark tests.
Technical specs
Technical information about the characteristics of the processor Intel Xeon W-2235 reveals important data that will help to make the right choice in favor of upgrading your computer or laptop to a more modern model.
Before we explore the detailed specifications Intel Xeon W-2235 we want to inform you that we will help with the answers to the following questions:
1) How many cores and threads does the processor Intel Xeon W-2235 have?
2) Is the processor Intel Xeon W-2235 productive enough for games or work programs?
3) Can I mine on a Intel Xeon W-2235 processor?
| CPU Cores / Threads: | 6 / 12 | |||
| Core architecture: | normal | |||
| A core: | 0x | |||
| B core: | 0x | |||
| Hyperthreading: | Yes | |||
| Overclocking: | No | |||
| Frequency: | 3.80 GHz | |||
| Turbo Frequency (6 Cores): | 4.60 GHz | |||
CPU generation and family
Processor generation Intel Xeon W-2235, as well as the family have an important role in the analysis of data. As a rule, you should pay attention not to the generation and family of the processor model when you upgrade your computer system, because the new families have a difference in the motherboard socket, which will entail additional costs for upgrading. Otherwise, each subsequent generation is improved by adding new and efficient processors to the family.
| Market price: | ca. 555 $ | |||
iGPU
Not every processor model supports an integrated graphics core, but this is a nice bonus for those who do not need a separate graphics card. See if the Intel Xeon W-2235 processor has an integrated graphics core and what features the manufacturer has implemented in this model.
| GPU (Turbo): | No turbo | |||
Hardware codec support
Find out which hardware codecs are supported by the processor Intel Xeon W-2235. Most often manufacturers embed proprietary add-ons, which are disclosed in the operating system by their functionality, so this unit is not considered in the overall performance rating of the model.
| h265 / HEVC (8 bit): | No | |||
| h265 / HEVC (10 bit): | No | |||
| h264: | No | |||
| VP8: | No | |||
| VP9: | No | |||
| AV1: | No | |||
| AVC: | No | |||
| VC-1: | No | |||
| JPEG: | No | |||
Memory Specifications
The type of memory supported, the number of supported RAM channels, its standard and bandwidth all affect the overall performance of the Intel Xeon W-2235 CPU. The type and maximum amount of memory the CPU supports will determine the model's performance in games, work applications, or mining. Pay attention to all parameters, especially useful when comparing two CPUs.
| Memory type: | DDR4-2933 | |||
| Max. Memory: | 1024 GB | |||
| Memory channels: | 4 | |||
| ECC: | Yes | |||
| AES-NI: | Yes | |||
Thermal Management (TDP)
The TDP values for the processor Intel Xeon W-2235 are shown in the table below. These parameters are very important and especially useful when choosing a new processor model to replace an old one. The TDP figure shows how much power you will need and what kind of cooling system you will need. Also, depending on the type of power supply, you may need a good motherboard with good quality power phases for your CPU and graphics card.
| TDP (PL1): | 130 W | |||
| TDP (PL2): | -- | |||
| TDP up: | -- | |||
| TDP down: | -- | |||
| Tjunction max.: | -- | |||
Additional specifications
Detailed processor specifications Intel Xeon W-2235. Here you will find out the L2 and L3 memory size (cacheable and affecting data processing). The manufacturing process is also very important, it is measured in nanometers and the smaller the better. As a rule, only the most modern models are produced by the manufacturing method of lithography. Also here is information on the socket of the motherboard and the date of manufacture of the model, the fresher the processor, the longer it will last until the next upgrade.
| Instruction set (ISA): | x86-64 (64 bit) | |||
| L2-Cache: | 6.00 MB | |||
| L3-Cache: | 8.25 MB | |||
| Architecture: | Cascade Lake SP / Glacier Falls W | |||
| Technology: | 14 nm | |||
| Virtualization: | VT-x, VT-x EPT, VT-d, vPro | |||
| Socket: | LGA 2066 | |||
| Release date: | Q4/2019 | |||
| Part Number: | CD8069504439102 | |||
Use Conditions
We are updating information about the use and destination of the Intel Xeon W-2235 processor, so if you have exact information about where the model is used, please let us know via the feedback form.
| Used in: | server | |||
Cinebench R15 (Single-Core) Intel Xeon W-2235
The list of the best processors for budget gaming desktops will help you decide on your choice. Compare the performance of the different models in our ranking, especially if you need a processor for your gaming PC and have a limited budget. Use our Cinebench R15 benchmark to see if your processor can handle today's powerful games. Also find out the following: - What's the most powerful gaming processor right now? - Do I need a powerful processor for gaming? - What is the fastest processor for gaming? - What makes a good processor for gaming? Buying the right processor for computer games is quite difficult. But our ranking of the best CPUs will help with the task.
